Features:
  • Simple all-electric design
  • Lightweight and easy to move
  • Adjustable temperature and flow rates
  • Fan-cooled 25rpm AC gear motor for long life
Performance:
  • Warm-ip Time: 30 minutes
  • Melt Rate: 10lb/hr
  • Viscosity: Maximum 5,500cps
  • Operating Temperature: 100-375F
  • Tank Overtemp Switch: Protects the meltunit if the tank thermostat fails. 400F is standard.
  • Pump Warm-up Thermostat: Prevents the pump motor from operating until tank reaches a safe temperature. 250F is standard.
    Pump Flow Output: Regulated between low and full flow by adjusting flow control valve.
Specifications:
  • Length = 15 in
  • Width = 12 in
  • Height = 15 in
  • Weight = 30 lbs
  • Volume = 7lbs
